Ortofon MC Quintet Black S
€0.00
We can also recommend these products
Buy together with
Product information "Ortofon MC Quintet Black S"
Die neue MC Quintet Serie setzt die Ortofon-Tradition kontinuierlicher Forschung und Innovation weiter fort!
Das runderneuerte Spitzenmodell MC Quintet Black S nutzt jetzt Saphir als Nadelträgermaterial, das eine noch höhere Präzision beim Schwingungstransfer ermöglicht.
- Moving Coil Prinzip
- Hohe Abtastfähigkeit
- Quintet Black S mit Saphirnadelträger für nochmals verbesserten Schwingungstransfer zu den Spulen
- Spulenwicklungen aus reinem Kupfer, Silber oder Aucurum
- Optimal geeignet für mittlere Tonarmmassen
- 1/2-Zoll Befestigung
- Unkomplizierte Montage
- Wie bei allen MC-Tonabnehmern, kann die Nadel nicht gewechselt werden
| Output voltage at 1000 Hz, 5cm/sec.: | 0.3 mV |
| Channel balance at 1 kHz: | < 1.0 dB |
| Channel separation at 1 kHz: | > 23 dB |
| Channel separation at 15 kHz: | > 15 dB |
| Frequency range at - 3dB: | 20 - 25.000 Hz |
| Frequency response 20-20.000 Hz: | +/- 1.5 dB |
| Tracking ability at 315Hz at recommended tracking force *): | 80 µm |
| Compliance, dynamic, lateral: | 15 µm/mN |
| Stylus type: | Nude Shibata |
| Stylus tip radius: | r/R 6/50 µm |
| Tracking force range: | 2.1-2.5 g (21-25 mN) |
| Tracking force, recommended: | 2.3 g (23 mN) |
| Tracking angle: | 20° |
| Internal impedance, DC resistance: | 5 Ohm |
| Recommended load impedance: | > 20 Ohm |
| Cartridge body material: | ABS/Aluminium |
| Coil wire material: | Aucurum |
| Cartridge colour: | Black |
| Cartridge weight: | 9 g |
