Product information "Ortofon 2MR Blue"
Alle Tonabnehmer der 2MR Serie sind um 4mm niedriger als die der 2M Serie!
Die Ortofon 2MR-Serie ist mit einem neu entwickelten Tonabnehmergehäuse für die optimierte Befestigung an flachen Plattenspielern konzipiert. Mit einer ultra-schlanken Höhenreduktion um 3 mm ist eine nahtlose Integration garantiert. Das schlanke Gehäuse des Tonabnehmers eliminiert die Notwendigkeit von Abstandshaltern oder Modifikationen, wodurch eine schnelle, einfache Montage mit nur zwei Schrauben gewährleistet wird.
Erlebt eine unvergleichliche Kompatibilität mit allen 2M Styli und erfreut euch am Hochleistungsmotorsystem mit Quad-Spulen und geteilten Polkernen, exklusiv für echte Ortofon-Tonabnehmer.
Technische Daten
Tonabnehmer-Typ: | MM (Moving-Magnet) |
Ausgangsspannung: | 5,5mV |
Verstärkeranschluss: | Phono MM |
Kanalabweichung bei 1 kHz: | 1,5dB |
Übersprechdämpfung bei 1kHz: | 25dB |
Übersprechdämpfung bei 15kHz: | 15dB |
Frequenzbereich: | 20 - 25.000Hz |
Frequenzgang: | 20 - 20.000Hz +2/-1dB |
Abtastfähigkeit bei 315Hz: | 80µm |
Nadelnachgiebigkeit: | 20µm/mN |
Abtastdiamant: | Elliptisch, nackt |
Verrundung: | r/R 8/18 µm |
Auflagekraftbereich: | 16-20mN (1,6-2,0g) |
empf. Auflagekraft: | 18mN (1,8g) |
Abtastwinkel: | 20 Grad |
Gleichstromwiderstand: | 1,3kOhm |
Induktivität: | 700mH |
empf. Abschlusswiderstand: | 47kOhm |
empf. Abschlusskapazität: | 150-300pF |
Gehäusematerial: | Noryl/Glas-Verbundwerkstoff |
Gewicht: | 7,2g |
Ersatz-Nadeleinschub: | Stylus 2M Blue |
